RF Series
|
BMB |
Gender
|
Jack (Female) |
Orientation (Body)
|
Straight |
Coupling
|
Push-on |
Finish
|
Gold |
RF Series 2
|
2.92 mm |
Gender 2
|
Plug (Male) |
Orientation 2 (Body)
|
Straight |
Electrical
|
Impedance
|
50 ohms |
Frequency
|
22 GHz |
Shielding Effectiveness
|
≥ -90 dB |
Dielectric withstanding Voltage
|
1500 VRMS |
Mechanical
|
Mating Cycles
|
500 |
Insertion Force
|
2.0 lbs |
Withdrawal Force
|
6 oz |
Environmental
|
Temperature Rating
|
-65°C to +165°C |
Corrosion (salt spray)
|
MIL-STD-202, Method 101, Condition B |
Thermal Shock
|
MIL-STD-202, Method 107, Condition B |
Shock
|
MIL-STD-202, Method 213, Condition I |
Vibration
|
MIL-STD-202, Method 204, Condition D |
Barometric Pressure (Altitude)
|
MIL-STD-202, Method 105, Condition C, 70k Ft. |
Moisture Resistance
|
MIL-STD-202, Method 106, Less Step 7B |
