P/N: 7029-3247

SMA Male R/A to SMPM Female 12" Cable Assembly for .085 Cable

In stock at Qty Order
Mouser Electronics 49
Newark 24
Farnell 24
Digi-Key Electronics 15
Products specifications
Attribute name Attribute value
RF Series SMA
Gender Plug (Male)
Termination Style Solder
Coupling Threaded
Orientation (Body) Right Angle
Impedance 50 ohms
RF Series 2 SMPM
Frequency 18 GHz
Gender 2 Jack (Female)
Cable Type 0.085 Flexible Coax
Orientation 2 (Body) Straight
Cable Length 12"
Electrical
Impedance (Ω) 50
Shielding Effectiveness ≥ -90 dB
Frequency GHz 18 GHz
Dielectric withstanding Voltage 1000 VRMS
Mating Cycles 500
Mechanical
Mating Torque 7 - 10 in - lbs
Inter-mate ability 2.92mm
Temperature Rating -65°C to +165°C
Corrosion (salt spray) MIL-STD-202, Method 101, Condition B
Environmental
Vibration MIL-STD-202, Method 204, Condition D
Shock MIL-STD-202, Method 213, Condition I
Thermal Shock MIL-STD-202, Method 107, Condition B
Moisture Resistance MIL-STD-202, Method 106, Less Step 7B
Barometric Pressure (Altitude) MIL-STD-202, Method 105, Condition C, 70k Ft.
