P/N: SF1621-60026-1S

2.4mm Female Solderless PCB Compression Mount Connector, 2 Hole, with 4.76mm Screws (CPW / Microstrip)

In stock at Qty Order
TTI Inc Global Headquarters 248
Mouser Electronics 175
Master Electronics 130
Heilind Electronics 36
Products specifications
Attribute name Attribute value
Family Solderless
RF Series 2.4 mm
Gender Jack (Female)
Orientation (Body) Straight
Coupling Threaded
Mounting Type PCB Vertical Launch
Body Style 2 Hole
Termination Style Solder-free
Number of Ports Single
Frequency 50 GHz
Finish Passivated
Impedance 50 ohms
Electrical
Impedance (Ω) 50
Dielectric withstanding Voltage 500 VRMS
Frequency GHz 50 GHz
Mating Cycles 500
Shielding Effectiveness ≥ -100 dB
Mechanical
Mating Torque 5 - 7 in - lbs
Temperature Rating -65°C to +165°C
Inter-mate ability 1.85mm
Corrosion (salt spray) MIL-STD-202, Method 101, Condition B
Environmental
Vibration MIL-STD-202, Method 204, Condition D
Shock MIL-STD-202, Method 213, Condition I
Thermal Shock MIL-STD-202, Method 107, Condition B
Moisture Resistance MIL-STD-202, Method 106, Less Step 7B
Barometric Pressure (Altitude) MIL-STD-202, Method 105, Condition C, 70k Ft.
