P/N: 1742-6002

BMA Female Snap-In Float Mount Connector for .141 Cable

In stock at Qty Order
Heilind Electronics 97
Microwave Components LLC 5
Products specifications
Attribute name Attribute value
RF Series BMA
Gender Jack (Female)
Orientation (Body) Straight
Coupling Push-on
Mounting Type Snap-in
Termination Style Solder
Number of Ports Single
Frequency 18 GHz
Cable Type 0.140 Flexible Coax
Impedance 50 ohms
Electrical
Frequency GHz 18 GHz
Impedance (Ω) 50
Shielding Effectiveness ≥ -90 dB
Mating Cycles 5000
Dielectric withstanding Voltage 1000 VRMS
Mechanical
Insertion Force 3.0 lbs
Withdrawal Force 1.5 lbs
Temperature Rating -65°C to +165°C
Corrosion (salt spray) MIL-STD-202, Method 101, Condition B
Environmental
Vibration MIL-STD-202, Method 204, Condition D
Shock MIL-STD-202, Method 213, Condition I
Moisture Resistance MIL-STD-202, Method 106, Less Step 7B
Barometric Pressure (Altitude) MIL-STD-202, Method 105, Condition C, 70k Ft.
Thermal Shock MIL-STD-202, Method 107, Condition B
