P/N: SF8711-6004

ZMA Male (130°|100°|130°) Connector for .085 Cable

Not available for this part number. Please contact us.
Products specifications
Attribute name Attribute value
RF Series ZMA
Coupling Keyed
Orientation (Body) Straight
Gender Plug (Male)
Termination Style Solder
Keyed Subtype 130-100-130
Frequency 18 GHz
Number of Ports Single
Impedance 50 ohms
Finish Passivated
Cable Type 0.085 Flexible Coax
Electrical
Frequency GHz 18 GHz
Impedance (Ω) 50
Shielding Effectiveness ≥ -90 dB
Dielectric withstanding Voltage 2500 VRMS
Mating Cycles 500
Mechanical
Mating Torque 4 in - oz
Temperature Rating -65°C to +165°C
Corrosion (salt spray) MIL-STD-202, Method 101, Condition B
Environmental
Vibration MIL-STD-202, Method 204, Condition D
Shock MIL-STD-202, Method 213, Condition I
Thermal Shock MIL-STD-202, Method 107, Condition B
Moisture Resistance MIL-STD-202, Method 106, Less Step 7B
Barometric Pressure (Altitude) MIL-STD-202, Method 105, Condition C, 70k Ft.
